ROM
1.Without cooling fan nor A/C,less power consumption.
2.The wind resistance is small,can be heat dissipation by itself due to the small gap.
3.The material is Aluminum,very much lightweight.
4.Using less bracket/frame.
5.Easy for maintenance
6.Specially designed for huge size screen.
SPECIFICATIONS

Item

ROM Series

ROM Series

ROM Series

Pixel Pitch

8.33mm-16.67mm

16.67mm-16.67mm

16.67mm-33.33mm

Scan Mode

1/16 Scan

1/8 Scan

1/6 Scan

Pixel Per Sq.m

7,200 Pixel

3,600 Pixel

1,800 Pixel

Transpparency

43%

70%

70%

LED Encapsulation

SMD3535

DIP346

DIP346

Module Size(W*H)

9.5*1000*11mm

9.5*1000*18mm

9.5*1000*18mm

Cabinet Weight

7.8KG

8.3KG

5.5KG

Maintenance Method

Front/Rear Serviceable

Cabinet Material

Aluminum

Cabinet Size(W*H*D)

500*1000*60mm

Refresh Rate

1920hz-3840hz

Color Temperature

6000K ±500(Adjustable)

Grey Scale

14bits

Brightness(Nits)

6500-9000nits

Average Power Consumption

155Watt/㎡

Max Power Consumption

450Watt/㎡

IP Protection

IP68

Operating Temperature

-10°C to 40°C

Working Voltage

100-240Volt(50-60hz)
