RID
1.Die-casting Aluminum makes the product sturdy and durable,provides great consistency and precision.
2.Low electric current, together with the RFC power supply, reduces the power consumption by over 15%.
3.Each component can be detached separately.The classic rental display with multiple specs meet the needs of various events.
4.Widely used in TV station,concert,entertainment show,supermarket,shopping mall,wedding ceremony,etc.
SPECIFICATIONS

Item

RID Seires

RID Seires

RID Seires

Pixel Pitch

2mm

2.5mm

3mm

LED Encapsulation

SMD1515

SMD2121

SMD2121

Module Size(W*H)

256*128mm

160*160mm

192*192mm

Scan Mode

1/40 Scan

1/16 Scan

1/16 Scan

Pixel Per Sq.m

250,000 Pixel

160,000 Pixel

111,111 Pixel

Cabinet Size(W*H*D)

512*512*75mm

480*480*75mm

576*576*75mm

Maintenance Method

Front Serviceable

Cabinet Material

Die Casting Aluminum

Refresh Rate

3840hz-4880hz

Color Temperature

9500K ±500(Adjustable)

Gray Scale

14-16bits

Cabinet Weight

7.8KG/Pieces

Brightness(Nits)

1100nits

Average Power Consumption

350-400Watt/㎡

Max Power Consumption

800Watt/㎡

IP Protection

IP43

Operating Temperature

-20°C to 50°C

Working Voltage

100-240Volt(50-60hz)CE Certificate
